200gsm Filament Woven Geotextile Fabric For Driveway ISO CE High Strength Geotextile

200gsm Filament Woven Geotextile Fabric For Driveway ISO CE High Strength Geotextile
200gsm Filament Woven Geotextile Fabric For Driveway ISO CE High Strength Geotextile 200gsm Filament Woven Geotextile Fabric For Driveway ISO CE High Strength Geotextile

Large Image :  200gsm Filament Woven Geotextile Fabric For Driveway ISO CE High Strength Geotextile

Product Details:
Place of Origin: CHINA
Brand Name: HASSAN
Certification: ISO CE
Model Number: NON WOVEN
Payment & Shipping Terms:
Minimum Order Quantity: 1*20FT CONTAINER
Price: $0.16 - $1.80/ Square Meter
Packaging Details: STANDARD EXPORT PACKAGE
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T
Supply Ability: 10000 Square Meter/Square Meters per Day

200gsm Filament Woven Geotextile Fabric For Driveway ISO CE High Strength Geotextile

Description
Application: Courtyard, Driveway Retaining Wall Model Number: PET
Geotextile Type: Non-Woven Geotextiles Fiber Type: Short Fiber, Long Fiber
Product Name: Woven Geotextile Fabric Weight: 200gsm
High Light:

200gsm Filament Woven Geotextile Fabric

,

Woven Geotextile Fabric For Driveway ISO CE

,

ISO CE High Strength Geotextile

200gsm Filament geotextile raw materials nonwoven geotextile geotextile




Product Description



1) Geotextile can make the water flow easily, and form a drainage channel in the soil, and then make the liquid and gas out of the soil.

2) Make use of its pulling resistance and deformation resistance that can strength the soil to reinforce the stability of the construction structure and improve the soil’s quality.

3) Make the focus proliferate, deliver and decompose efficiently and prevent the soil from destruction from outside factor.

4) Prevent the top and bottom layer’s gravel, soil and concrete from mixer.

5) The mesh cannot be plugged easily – for the strain and moving quality of the network that formed by the antitype fiber.

6) High soaking quality—at the pressure of soil, it also can keep good soaking quality.

7) Corrosion resistant – using the polypropylene and polyester as raw material, it can resist the sour and aid, erosion, boring and oxidation.

8) The construction is easy; the weight is light, convenient for using, and it making construction easy.





UV Resistant Filtration Drainage Reinforcement Polyester PP Polypropylene Nonwoven Geotextile

Item Unit Index
100g 150g 200g 250g 300g 350g 400g 500g 600g 800g
Grab Tensile Strength(MD/CD) N ≥350 ≥600 ≥800 ≥850 ≥1100 ≥1300 ≥1500 ≥2000 ≥2400 ≥3200
Grab Elongation(MD/CD) % 50-90 50-100
Trapezoidal Tear Strength(MD/CD) N ≥135 ≥200 ≥350 ≥380 ≥420 ≥470 ≥500 ≥580 ≥660 ≥840
CBR Mullen Burst Strength KN 1.3 1.8 2.0 2.5 3.5 4 4.3 5.5 6.5 8.5
Breaking Strength KN ≥5.0 ≥5.5 ≥11 ≥12 ≥16 ≥19 ≥22 ≥28 ≥35 ≥50
Breaking Elongation % 50-100 50-90
Dry Sieve Size O90 mm



















Specifications 100 150 200 250 300 350 400 450 500 600 800 Remarks
Deviation of mass per unit(%) -6 -6 -6 -5 -5 -5 -5 -5 -4 -4 -4 -
Thickness(mm≥) 0.8 1.2 1.6 1.9 2.2 2.5 2.8 3.1 3.4 4.2 5.5 -
Deviation of width(%) -0.5 -0.5 -0.5 -0.5 -0.5 -0.5 -0.5 -0.5 -0.5 -0.5 -0.5 -
Tensile strength(KN/m≥) 4.5 7.5 10.0 12.5 15.0 17.5 20.5 22.5 25.0 30.0 40.0 Longitudinal Horizontal
Break elongation ratio(≤%) 40-80 -
CBR bursting strength(KN≥) 0.8 1.4 1.8 2.2 2.6 3.0 3.5 4.0 4.7 5.5 7.0 -
Equivalent opening size090(095)mm 0.07-0.2 -
Tearing strength (KN≥) 0.14 0.21 0.28 0.36 0.42 0.49 0.56 0.63 0.70 0.82 1.10 Longitudinal Horizontal
Property High strength,Anti-acid and alkali,Abrasion resisting,Flexibility,and easy for construction.
Size of package Width 1-6m,length 50-100m(or as request)
