Product Details:
|
| Name: | Geotextile For Construction Road,Woven Geotextile Price,Hot Sale Polypropylene Woven Monofilament Geotextile Fabric,woven Monofilament Geotextile Fabric Membrane Price For Road | Material: | Polyester |
|---|---|---|---|
| Application: | Reinforcement,Building Construction,Weed Control,Filtration,Garden Used | Color: | White |
| Geotextile Type: | Woven Geotextiles | Width: | Accept Customer-made |
| High Light: | Non Woven Geotextile Drainage Fabric,Polyester Geotextile Drainage Fabric,150GSM Non Woven Drainage Fabric |
||
Factory Supply 150GSM Non Woven Geotextile Drainage Fabric
Product description:
PET/PP woven geotextile is made of h tenacity and high molecular weight polyester or polypropylene yarns, Wear-resisting, bursting resistant and high tensile strength, also provide different strength at low elongation.
PET/PP woven geotextile can be applied in soil stabilization embankment reinforced wall and slope, sidewalk paver, coastal and riverbank revetments, landfill separators and capping etc.
Specifications: Range:50kn~1000kn
| Item | Unit | 65x65 | 150x50 | 200x50 | 600x50 | 1000x50 | 200x200 | |
| Tensile strength | MD | KN/m | 65 | 150 | 200 | 600 | 1000 | 200 |
| CD | KN/m | 65 | 50 | 50 | 50 | 50 | 200 | |
| Elongation of break | MD | %≤ | 9 | 10 | 11 | 10.5 | 10.5 | 12 |
| CD | %≤ | 9 | 10 | 10 | 10 | 10 | 8 | |
| Bursting strength | KN/m | 3 | 9 | 10 | / | / | 20 | |
| Equivalent opening size(O95) | mm | 0.05-0.5 | ||||||
Product features:
1) high strength, at the same gram weight, the longitudinal and horizontal tension are higher than other needled non-woven fabrics.
2) high extension, the product has a good elongation under a certain stress, can make geotextile adapt to uneven base.
3) high temperature resistance. The temperature of asphalt laying on geotextile is generally 150℃ ~ 165℃, while the polyester spunbonded needle cloth for geotextile begins to soften at more than 210℃. At this time, the product can still maintain the structural integrity and physical properties unchanged.
4) plane drainage and vertical permeability. Due to the large thickness of the product and its reinforcement by acupuncture, it has good plane drainage performance and vertical permeability.
5) anti-aging, the product has very high anti-ultraviolet radiation ability, not easy to degradation.
6) corrosion resistance: the product is resistant to corrosion of common chemical substances in soil, gasoline, diesel, etc.
7) friction resistance, the friction coefficient of the product is higher than other conventional geotextile, not easy to fluff and damage.
8) creep resistance. The product has good creep resistance and long-lasting function
