150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced

150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced
150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced
150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced 150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced 150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced 150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced 150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced 150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced 150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced

Large Image :  150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced

Product Details:
Place of Origin: CHINA
Brand Name: HASSAN
Certification: ISO9001 CE
Model Number: PET150-50
Payment & Shipping Terms:
Minimum Order Quantity: 1000 Meters
Price: USD0.5-0.9/M2
Packaging Details: packing with PE fabirc,
Delivery Time: 5-8 work days
Supply Ability: 300000 Meters/ week

150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced

Description
Name: Geotextile For Construction Road,Woven Geotextile Price,Hot Sale Polypropylene Woven Monofilament Geotextile Fabric,woven Monofilament Geotextile Fabric Membrane Price For Road Material: Polyester
Application: Reinforcement,Building Construction,Weed Control,Filtration,Garden Used Color: White
Geotextile Type: Woven Geotextiles Width: Accept Customer-made
High Light:

150kn Woven Geotextile Fabric

,

Reinforced Woven Geotextile Fabric

,

320gsm High Strength Geotextile

150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced



Product description:

PET/PP woven geotextile is made of h tenacity and high molecular weight polyester or polypropylene yarns, Wear-resisting, bursting resistant and high tensile strength, also provide different strength at low elongation.

PET/PP woven geotextile can be applied in soil stabilization embankment reinforced wall and slope, sidewalk paver, coastal and riverbank revetments, landfill separators and capping etc.


SpecificationsRange:50kn~1000kn

Item Unit 65x65 150x50 200x50 600x50 1000x50 200x200
Tensile strength MD KN/m 65 150 200 600 1000 200
CD KN/m 65 50 50 50 50 200
Elongation of break MD %≤ 9 10 11 10.5 10.5 12
CD %≤ 9 10 10 10 10 8
Bursting strength KN/m 3 9 10 / / 20
Equivalent opening size(O95) mm 0.05-0.5



150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced 0



Product features: What is woven geotextile used for?

1. High strength: Use high-strength industrial polypropylene, polyester, nylon and other synthetic fibers as raw materials, which have high original strength. After weaving, it becomes a regular interwoven structure, and the comprehensive load-bearing capacity is further improved.



2. Durability: Synthetic chemical fiber is characterized by resistance to change, decomposition, and weathering. It can maintain its original characteristics for a long time.



3. Corrosion resistance: Synthetic chemical fiber is generally resistant to acid, alkali, insects and mold.



4. Water permeability: Woven fabric can effectively control the pores of its structure to achieve a certain water permeability.



5. Convenient storage and transportation: Because it is light in weight and can be packaged according to certain requirements, transportation, storage, and construction are very convenient.



6. Application range: A series of industrial products of geotechnical materials formed to adapt to various characteristics and requirements of geotechnical engineering. Widely used in rivers, coasts, harbors, highways, railways, docks, etc.



7. Function and application of filament woven geotextile:

Woven geotextiles are mainly used in railway subgrade construction, highway subgrade construction, foundation use of various construction sites, dike retaining, intercepting sand and soil loss, tunnel waterproofing membrane use, urban green flower project use, underground garage waterproofing, waterproof material Substrates, artificial lakes, pools, seepage and waterproof use, clay liners, can also be used as concrete foundation cushions, especially when geological instability brings uneven settlements, woven geotextiles, woven needle-punched geotextiles It has a good water-conducting function and strong tensile strength. It can form a filtering and drainage effect inside the fill, so that the foundation soil is not lost, and the building structure is strengthened and the foundation is solid. The product has good dimensional stability, anti-aging, strong crack resistance, flexibility, and is not afraid of mold. It is a new material that is non-toxic, non-volatile, and environmentally friendly.

150-50kn Woven Geotextile Fabric 320gsm High Strength Reinforced 1
