Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag

Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag
Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag

Large Image :  Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag

Product Details:
Place of Origin: CHINA
Brand Name: HASSAN
Certification: ISO9001
Model Number: TUBE
Payment & Shipping Terms:
Minimum Order Quantity: One Pieces
Payment Terms: L/C, T/T

Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag

Description
Geotextile Type: Woven Geotextiles Color: Black
Material: 100% Polypropylene Width: Can Be Custom-made
Length: Can Be Custom-made Weight: 100--800g/M2
Application: Coastal Protection Size: Can Be Custom-made
Sample: Free Stock Sample
High Light:

Geotube Sludge Dewatering Bag

,

Dewatering Filtering Geotube

,

Coastal Protection Sludge Dewatering Bag

BEST Quality Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag



Description

Geotextile Tube is one of the most effective components that are most usually used in protective structure of waterproof erosion. Soft mattress is covered to the places where water flows to reduce the impact energy of water flow and protect soil particles from being flown away by water flow by means of its filtration function, thus, ensuring the stability of soil mass.





Technical data

Item Unit Technical Parameters
Tube 500 Tube 750 Tube 1000
Breaking strength MD KN/m >= 70 120 200
CD KN/m >= 90 120 200
Elongation of break MD %<= 20 20 20
CD %<= 10 10 10
Sewing Tensile strength >=% 80 80 80
Bursting Strength(CBR) KN>= 8 14 18
Equivalent opening size(O90) mm 0.2-0.6 0.2-0.6 0.2-0.6
Permeability(Q50) L/m2/s>= 20 13 15
UV-resistance(500HRS strength retention) %>= 90 80 80




Geotextile Tube Features

Fabric: High Strength Geotextile

  • Length: up to 200 ft.
  • Circumference: up to 120 ft.
  • Effectively Filters out Silt, Sediment, Sludge, and Waste
  • Easy removal and disposal of solids
  • Reliable in all weather conditions
  • Reduces risks in operational safety

Geotextile Tube Benefits

  • Designed for Large Dewatering Projects
  • High Strength Woven Geotextile Fabrics
  • Large Sizes Available
  • Easy to Size for Specific Requirements
  • Cost effective and low maintenance
  • Efficient, versatile and environmental friendly


Application


1. Bank protection
2. Dyke protection
3. Base protection
4. Embankment engineering
5. Dam engineering
6. Cofferdam engineering



The whole process has three-steps:

Step 1: Filling -- Sludge (dredged material) is pumped into the tube container. Environmentally-safe polymers are added to the sludge, which makes the solids bind together and water separate. container's unique fabric confines the fine grains of the material.

Step 2: Dewatering -- Clear effluent water simply drains from the tube container through the small pores in the specially engineered textile. This results in effective dewatering and efficient volume reduction of the contained materials. And this volume reduction allows for the repeated filling of the tube container. Over 99% of solids are captured, and clear filtrate can be collected and recirculated through the system. The decanted water is often of a quality that can be reused/returned for processing or returned to native waterways without additional treatment.

Step 3: Consolidation -- After the final cycle of filling and dewatering, the solids remain in the bag and continue to densify due to desiccation as residual water vapor escapes through the fabric. Volume reduction can be as high as 90 percent. When full, the tube container and contents can be deposited at a landfill, remain on-site, or the solids can be removed and land-applied when appropriate.

Dewatering Geotube Filtering Geotube Sludge Dewatering Bag And Geobag 0
