Long Fiber Non Woven Geotextile For Infrastructure And Construction Stability Solutions

Large Image : Long Fiber Non Woven Geotextile For Infrastructure And Construction Stability Solutions

Product Details:

Place of Origin:	CN
Brand Name:	Haisan
Certification:	ISO
Model Number:	hs-long

Payment & Shipping Terms:

Minimum Order Quantity:	1000㎡
Price:	USD 0.2-3.5
Packaging Details:	PP Woven Bag
Delivery Time:	5-10 work days
Payment Terms:	L/C,T/T
Supply Ability:	1000000㎡ per month

Contact Now

Long Fiber Non Woven Geotextile For Infrastructure And Construction Stability Solutions

Description

Type:	Non-woven	Feature:	Corrosion Resistant, Oxidation Resistance, Wear-resistant
Usage:	Insulation, Water Filter, Soil Reinforced	Mightiness At Break:	2.5-25.0kN/M Or More
Elongation:	50-70%	Elongation At Break:	25%--100%
Transport Package:	Standard Packaging Or Customized	Width Deviation For Range:	-0.5%M

Long Fiber Non Woven Geotextile For Infrastructure And Construction Stability Solutions

Reliability in large-scale infrastructure begins with superior material selection. Our Long Fiber Non-woven Geotextile is manufactured through a high-tech spunbond process using 100% virgin polyester (PET) chips. By creating an endless, multi-directional fiber structure, this high-tenacity geotextile delivers exceptional mechanical strength and hydraulic conductivity compared to traditional short-fiber alternatives. Its high CBR puncture resistance and superior tensile strength make it an indispensable geosynthetic solution for heavy-duty stabilization. Designed to withstand the rigors of construction, this filament non-woven fabric ensures optimal performance in filtration, separation, and reinforcement, providing a permanent structural foundation for the world’s most challenging civil engineering projects.

Long Fiber Non Woven Geotextile For Infrastructure And Construction Stability Solutions 0

Long Fiber Non Woven Geotextile For Infrastructure And Construction Stability Solutions 1

Technical Specifications

Specification	100	150	200	300	400	500	600	800	Remark
Quality deviation per unit acreage%	-6	-6	-6	-5	-5	-4	-4	-4
Thickness,mm≥	0.8	1.2	1.6	2.2	2.8	3.4	4.2	5.5
Width deviation for range,%m	-0.5
Mightiness at break,KN/m ≥	4.5	7.5	10.0	15.0	20.5	25.0	30.0	40.0	Vertical and horizontal
Elongation at break,%	40-80								Vertical and horizontal
CBR bursting strength,KN≥	0.8	1.4	1.8	2.6	3.5	4.7	5.5	7.0
Effective aperture O90(O95)mm	0.07-0.20
Vertical osmotic coefficient,cm/s	K x(10^-1-10^-3)								K=1.0-9.9
Tearing strength, KN≥	0.14	0.21	0.28	0.42	0.56	0.70	0.82	1.10	Vertical and horizontal

Why Choose Our Nonwoven Geotextiles?

Advanced Spunbond Production: We utilize world-class spunbond production lines that ensure the fibers are distributed with extreme uniformity, resulting in zero weak points throughout the roll.
Long-Term Durability: Engineered for a design life of over 50 years, our products are highly resistant to biological degradation and chemical aging in acidic or alkaline soils.
Unmatched Tensile Performance: Our filament geotextiles offer a higher strength-to-weight ratio, allowing you to achieve superior reinforcement with less material volume.

Long Fiber Non Woven Geotextile For Infrastructure And Construction Stability Solutions 2

Primary Applications

High-Speed Railway & Airport: Stabilization of subgrades and runways where high mechanical performance and long-term durability are critical.
Large-Scale Hydraulic Projects: Reinforcement of dam cores, canal linings, and reservoir banks to manage water pressure and prevent soil erosion.
Highway & Bridge Construction: Effective separation of aggregate layers to maintain drainage integrity and prevent the mixing of sub-base materials.
Tunnel Engineering: Used for drainage and protection in tunnel lining systems to channel seepage and protect the waterproof membrane.

Long Fiber Non Woven Geotextile For Infrastructure And Construction Stability Solutions 3

Frequently Asked Questions (FAQ)

Q1: Are you manufacturer or trading company?

A: We are a professional manufacturer of geosynthetic materials. Our factory is in Tai'an, sales office is in Qingdao.

Q2: Which country did you export?

A: Our products have been exported to more than 20 countries all over the world, including USA, Canada, Poland, Switzerland, Japan, Southeast Asia, The Middle East, Africa, Australia etc.

Q3: What is your MOQ?

A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
