Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization

Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization
Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization

Large Image :  Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization

Product Details:
Place of Origin: CN
Brand Name: Haisan
Certification: ISO
Model Number: hs-nonwoven
Payment & Shipping Terms:
Minimum Order Quantity: 1000㎡
Price: USD 0.2-3.5
Packaging Details: PP Woven Bag
Delivery Time: 5-10 work days
Payment Terms: L/C,T/T
Supply Ability: 1000000㎡ per month

Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization

Description
Tensile Strength: 10-50 KN/m Color: White
Material: Polypropylene Or Polyester Type: Non-woven
Elongation At Break: 25-100% Cbr Bursting Strength: 0.3-4.0kN Or More

Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization

Our Short Fiber Geotextile features a highly irregular, interconnected maze of short synthetic fibers that are mechanically bound through a specialized needle-punching matrix. This distinct structural network allows the fabric to absorb and distribute localized heavy stresses, making it a reliable solution for structural stabilization. Acting as a hydraulic gatekeeper, this non-woven short fiber fabric allows water to pass through freely while preventing fine silts from migrating into clean aggregate layers. Its excellent conformability ensures it wraps seamlessly around irregular rock profiles, creating a durable protective barrier that prevents biological clogging and preserves soil layers over time.

Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization 0

Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization 1

Technical Specifications
Specification 100 150 200 300 400 500 600 800 Remark
Quality deviation per unit acreage% -8 -8 -8 -7 -7 -6 -6 -6
Thickness,mm≥ 0.9 1.3 1.7 2.4 3.0 3.6 4.1 5.0
Width deviation for range,%m 0.5
Mightiness at break,KN/m ≥ 2.5 4.5 6.5 9.5 12.5 16.0 19.0 25.0 Vertical and horizontal
Elongation at break,% 25-100 Vertical and horizontal
CBR bursting strengthk,KN≥ 0.3 0.6 0.9 1.5 2.1 2.7 3.2 4.0
Effective aperture O90(O95)mm 0.07-0.20
Vertical osmotic coefficient,cm/s K x(10-1-10-3) K=1.0-9.9
Tearing strength, KN≥ 0.08 0.12 0.16 0.24 0.33 0.42 0.46 0.60 Vertical and horizontal
Why Choose Our Geotextiles?
  • Superior Fabric Uniformity: Our advanced needle-punching tech ensures zero thin spots and consistent flow rates, preventing unexpected site failures.
  • Eco-Safe Material Matrix: Made from chemically inert, virgin-grade fibers that endure aggressive soil conditions without degrading or leaching.
  • 24/7 Remote Tech Support: Our engineers provide instant online consulting for roll layout calculations and installation troubleshooting to keep your projects on track.
Primary Applications
  • Asphalt Road Overlays: Absorbing stress between old concrete roads and new asphalt toppings to retard reflective cracking.
  • Sports Field Sub-bases: Heap leach pads, evaporation ponds, and oil & gas containment.
  • Gabion Wall Linings: Placed behind wire gabion baskets to prevent the backfill earth from washing out through the rock voids.
  • Foundation Mud-Control: Installed on soft construction access roads to prevent heavy machinery from sinking into wet subgrade soil.

Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization 2

Premium Needle-Punched Short Fiber Non Woven Geotextile Fabric For Soil Stabilization 3

Frequently Asked Questions (FAQ)

Q1: Are you manufacturer or trading company?

A: We are a manufacturer.

Q2: Which country did you export?

A: Our products have been exported to more than 20 countries all over the world, including USA, Canada, Poland, Switzerland, Japan, Southeast Asia, The Middle East, Africa, Australia etc.

Q3: What is your MOQ?

A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
