Product Details:
|
| Tensile Strength: | 10-50 KN/m | Color: | White |
|---|---|---|---|
| Material: | Polypropylene Or Polyester | Type: | Non-woven |
| Elongation At Break: | 25-100% | Cbr Bursting Strength: | 0.3-4.0kN Or More |
Our Short Fiber Geotextile features a highly irregular, interconnected maze of short synthetic fibers that are mechanically bound through a specialized needle-punching matrix. This distinct structural network allows the fabric to absorb and distribute localized heavy stresses, making it a reliable solution for structural stabilization. Acting as a hydraulic gatekeeper, this non-woven short fiber fabric allows water to pass through freely while preventing fine silts from migrating into clean aggregate layers. Its excellent conformability ensures it wraps seamlessly around irregular rock profiles, creating a durable protective barrier that prevents biological clogging and preserves soil layers over time.
![]()
![]()
| Specification | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 800 | Remark |
|---|---|---|---|---|---|---|---|---|---|
| Quality deviation per unit acreage% | -8 | -8 | -8 | -7 | -7 | -6 | -6 | -6 | |
| Thickness,mm≥ | 0.9 | 1.3 | 1.7 | 2.4 | 3.0 | 3.6 | 4.1 | 5.0 | |
| Width deviation for range,%m | 0.5 | ||||||||
| Mightiness at break,KN/m ≥ | 2.5 | 4.5 | 6.5 | 9.5 | 12.5 | 16.0 | 19.0 | 25.0 | Vertical and horizontal |
| Elongation at break,% | 25-100 | Vertical and horizontal | |||||||
| CBR bursting strengthk,KN≥ | 0.3 | 0.6 | 0.9 | 1.5 | 2.1 | 2.7 | 3.2 | 4.0 | |
| Effective aperture O90(O95)mm | 0.07-0.20 | ||||||||
| Vertical osmotic coefficient,cm/s | K x(10-1-10-3) | K=1.0-9.9 | |||||||
| Tearing strength, KN≥ | 0.08 | 0.12 | 0.16 | 0.24 | 0.33 | 0.42 | 0.46 | 0.60 | Vertical and horizontal |
![]()
![]()
Q1: Are you manufacturer or trading company?
A: We are a manufacturer.
Q2: Which country did you export?
A: Our products have been exported to more than 20 countries all over the world, including USA, Canada, Poland, Switzerland, Japan, Southeast Asia, The Middle East, Africa, Australia etc.
Q3: What is your MOQ?
A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
