Product Details:
|
| Item: | Non Woven Geotextile Filter Fabric | Kind: | Non Woven |
|---|---|---|---|
| Use: | Road|highway | Gram Weight: | 100~800 G/m2 |
| Package: | Customerised | Tensilestrength: | 10-50 KN/m |
| Sample: | Accept |
When building structures on soft, muddy dirt, mixing gravel with subgrade soil causes early road cracking. Our needle-punched short fiber geotextile provides a reliable, cost-effective separating layer to solve this common construction headache. This versatile short fiber non woven geotextile functions like a high-flow filter mat, allowing heavy rain and underground water to drain through easily while holding back tiny dirt particles. By installing this rugged nonwoven drainage fabric between different soil layers, you prevent wet mud from pumping upward into your clean stone base. It is the perfect choice for stabilizing driveway foundations, backyard French drains, and heavy transport roads, ensuring your construction project stays level and rut-free for years.
![]()
| Specification | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 800 | Remark |
|---|---|---|---|---|---|---|---|---|---|
| Quality deviation per unit acreage% | -8 | -8 | -8 | -7 | -7 | -6 | -6 | -6 | |
| Thickness,mm≥ | 0.9 | 1.3 | 1.7 | 2.4 | 3.0 | 3.6 | 4.1 | 5.0 | |
| Width deviation for range,%m | 0.5 | ||||||||
| Mightiness at break,KN/m ≥ | 2.5 | 4.5 | 6.5 | 9.5 | 12.5 | 16.0 | 19.0 | 25.0 | Vertical and horizontal |
| Elongation at break,% | 25-100 | Vertical and horizontal | |||||||
| CBR bursting strengthk,KN≥ | 0.3 | 0.6 | 0.9 | 1.5 | 2.1 | 2.7 | 3.2 | 4.0 | |
| Effective aperture O90(O95)mm | 0.07-0.20 | ||||||||
| Vertical osmotic coefficient,cm/s | K x(10-1-10-3) | K=1.0-9.9 | |||||||
| Tearing strength, KN≥ | 0.08 | 0.12 | 0.16 | 0.24 | 0.33 | 0.42 | 0.46 | 0.60 | Vertical and horizontal |
![]()
![]()
A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
Contact Person: Mrs. Grace Sun
Tel: 86-155 8864 6508
