Product Details:
|
| Item: | Non Woven Geotextile Filter Fabric | Kind: | Non Woven |
|---|---|---|---|
| Use: | Road|highway | Gram Weight: | 100~800 G/m2 |
| Package: | Customerised | Tensilestrength: | 10-50 KN/m |
| Sample: | Accept |
Railway tracks and highway bases built over soft clay foundations often suffer from "mud pumping," where wet dirt forces its way up into the clean gravel ballast. Our industrial-grade short fiber polypropylene geotextile is specifically designed to eliminate this structural failure. This thick, tough short fiber protection mat provides a heavy-duty separating barrier that withstands intense structural vibrations and continuous traffic loads. It allows subgrade moisture to vent upward and drain away horizontally while keeping muddy soil particles strictly locked below. Engineered as a highly resilient nonwoven stabilization sheet, it stabilizes the soil foundation, protects expensive track ballast, and extends the lifespan of heavy transport infrastructures.
![]()
| Specification | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 800 | Remark |
|---|---|---|---|---|---|---|---|---|---|
| Quality deviation per unit acreage% | -8 | -8 | -8 | -7 | -7 | -6 | -6 | -6 | |
| Thickness,mm≥ | 0.9 | 1.3 | 1.7 | 2.4 | 3.0 | 3.6 | 4.1 | 5.0 | |
| Width deviation for range,%m | 0.5 | ||||||||
| Mightiness at break,KN/m ≥ | 2.5 | 4.5 | 6.5 | 9.5 | 12.5 | 16.0 | 19.0 | 25.0 | Vertical and horizontal |
| Elongation at break,% | 25-100 | Vertical and horizontal | |||||||
| CBR bursting strengthk,KN≥ | 0.3 | 0.6 | 0.9 | 1.5 | 2.1 | 2.7 | 3.2 | 4.0 | |
| Effective aperture O90(O95)mm | 0.07-0.20 | ||||||||
| Vertical osmotic coefficient,cm/s | K x(10-1-10-3) | K=1.0-9.9 | |||||||
| Tearing strength, KN≥ | 0.08 | 0.12 | 0.16 | 0.24 | 0.33 | 0.42 | 0.46 | 0.60 | Vertical and horizontal |
![]()
![]()
A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
Contact Person: Mrs. Grace Sun
Tel: 86-155 8864 6508
