Product Details:
|
| Filtration Efficiency: | Effective Soil Filtration | Type: | Non-woven |
|---|---|---|---|
| Applying Area: | Road Way | Fiber Type: | Long Fiber |
| Tensile Strength: | 10-50 KN/m | Feature: | UV-protection Treatment |
| Specification: | 100~800g/m2 |
Building a lasting road or gravel driveway means keeping your expensive surface stones from sinking into the soft mud below. Our practical nonwoven road construction fabric acts as a tough separation layer between the dirt ground and your crushed gravel. It completely stops stones from disappearing into wet mud after heavy rain, keeping your road flat, solid, and free of deep ruts. This simple but highly effective driveway geotextile saves you from constantly buying new gravel to fill potholes year after year.
![]()
![]()
|
Specification
|
100
|
150
|
200
|
300
|
400
|
500
|
600
|
800
|
Remark
|
|
Quality deviation per unit acreage%
|
-6
|
-6
|
-6
|
-5
|
-5
|
-4
|
-4
|
-4
|
|
|
Thickness,mm≥
|
0.8
|
1.2
|
1.6
|
2.2
|
2.8
|
3.4
|
4.2
|
5.5
|
|
|
Width deviation for range,%m
|
-0.5
|
|
|||||||
|
Mightiness at break,KN/m ≥
|
4.5
|
7.5
|
10.0
|
15.0
|
20.5
|
25.0
|
30.0
|
40.0
|
Vertical and horizontal
|
|
Elongation at break,%
|
40-80
|
||||||||
|
CBR bursting strength,KN≥
|
0.8
|
1.4
|
1.8
|
2.6
|
3.5
|
4.7
|
5.5
|
7.0
|
|
|
Effective aperture O90(O95)mm
|
0.07-0.20
|
|
|||||||
|
Vertical osmotic coefficient,cm/s
|
K x(10-1-10-3)
|
K=1.0-9.9
|
|||||||
|
Tearing strength, KN≥
|
0.14
|
0.21
|
0.28
|
0.42
|
0.56
|
0.70
|
0.82
|
1.10
|
Vertical and horizontal
|
Saves Expensive Gravel: By stopping the mud from swallowing your stones, this fabric reduces the amount of base gravel you need to buy by up to 30%.
Lets Rainwater Pass Freely: The porous nonwoven structure allows heavy rain to drain straight through into the soil, keeping the road surface dry.
Easy for Any Crew to Install: Simply unroll it over the dirt by hand and cut it to size with a standard utility knife—no special heavy equipment needed.
Factory Direct Bulk Pricing: We manufacture these rolls in bulk and ship directly to your site, cutting out middleman hardware store markups.
![]()
Gravel Driveways: Placed directly over dirt before dumping crushed stone to prevent muddy potholes from forming around homes or farms.
Rural Dirt Roads: Reinforcing the base of unpaved country roads so heavy trucks and tractors do not get stuck in deep mud ruts.
Temporary Haul Roads: Providing a quick, stable running surface over soft ground for dump trucks entering and exiting messy construction sites.
Roadside Drainage Trenches: Wrapping French drain pipes along the side of the road to filter out dirt while quickly draining storm puddles away.
![]()
Q1: Can this Geotextile handle heavy rocks dropped onto it?
A: Yes, our high-grade long fiber geotextile has excellent elongation and puncture toughness, meaning it can absorb the impact of heavy gravel or rip-rap stones without tearing.
Q2: Are you manufacturer or trading company?
A: We are manufacturer.
Q3: What is your MOQ?
A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
