Product Details:
|
| Item: | Non Woven Geotextile Filter Fabric | Kind: | Non Woven |
|---|---|---|---|
| Use: | Road/highway/garden | Gram Weight: | 100~800 G/m2 |
| Package: | Customerised | Tensilestrength: | 10-50 KN/m |
| Sample: | Accept |
Moving river currents and waves can slowly wash away loose shoreline soil, eventually causing the entire bank to collapse into the water. Our nonwoven geotextile fabric acts as a tough, protective shield beneath heavy rocks and concrete armor blocks. This high-flow erosion control mat lets water drain back into the river freely to release pressure, while firmly holding the underlying dirt in place so the shoreline stays perfectly stable.
![]()
![]()
| Specification | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 800 | Remark |
|---|---|---|---|---|---|---|---|---|---|
| Quality deviation per unit acreage% | -8 | -8 | -8 | -7 | -7 | -6 | -6 | -6 | |
| Thickness,mm≥ | 0.9 | 1.3 | 1.7 | 2.4 | 3.0 | 3.6 | 4.1 | 5.0 | |
| Width deviation for range,%m | 0.5 | ||||||||
| Mightiness at break,KN/m ≥ | 2.5 | 4.5 | 6.5 | 9.5 | 12.5 | 16.0 | 19.0 | 25.0 | Vertical and horizontal |
| Elongation at break,% | 25-100 | Vertical and horizontal | |||||||
| CBR bursting strengthk,KN≥ | 0.3 | 0.6 | 0.9 | 1.5 | 2.1 | 2.7 | 3.2 | 4.0 | |
| Effective aperture O90(O95)mm | 0.07-0.20 | ||||||||
| Vertical osmotic coefficient,cm/s | K x(10-1-10-3) | K=1.0-9.9 | |||||||
| Tearing strength, KN≥ | 0.08 | 0.12 | 0.16 | 0.24 | 0.33 | 0.42 | 0.46 | 0.60 | Vertical and horizontal |
Stops Soil, Lets Water Flow: Engineered with precise micro-openings that block fine mud while handling massive volumes of rushing water.
Cushions Heavy Rock Drops: Densely needle-punched to absorb the heavy impact of large, sharp boulders dropped during construction.
Resists Rotting and Algae: Completely immune to river salt, chemical fertilizers, and water mold, keeping its strength underwater for decades.
Wide Roll Sizes Available: We supply wide rolls to cover large river banks with fewer overlapping seams, saving you installation time
River Bank Slopes: Installed directly under heavy riprap stones to stop fast currents from washing dirt out through rock gaps.
Lake Shorelines: Lining sandy beaches and lake edges below stone retaining walls to prevent wave erosion.
Culvert Outlets: Placed beneath rock aprons where pipe water gushes out, preventing deep mud holes from forming.
Bridge Abutment Protections: Wrapping soil foundations around concrete bridge supports to prevent underwater scour.
![]()
![]()
A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
