Product Details:
|
| Material: | HDPE | Color: | Can Be Customized |
|---|---|---|---|
| Package: | Woven Bag | Length: | 50-200m/roll |
| Width: | 1-5.8m | Thickness: | 0.2-5mm |
| High Light: | 3mm Plastic Roll Pond Liner ASTM,HASSAN Roll Pond Liner 3mm,3mm ASTM Swimming Pool Liner |
||
Introduction:
LDPE geomembrane adopts low density polyethylene film as basic impervious material, with geotechnical cloth as water conducting layer, through two stages extrusion, three rollers calendering coiled material. Its density is 0.916 - 0.930 g/cm3. Low density, good transparency, soft nature, with good extension property, electricity insulation, chemical stability, processability and resistance to low temperature (resistant to -70°C). What's more, it remains good mechanical strength, more elasticity and flexibility than HDPE geomembrane, and easy construction. At the same time, it features non-toxic, smooth and flat surface, corrosion resistance, high tensile strength, good shape and lightweight. LDPE geomembrane is applicable for pools, canals, embankments, farms, landfill, tunnel waterproof and seepage control.
HDPE Geomembrane pond liner TechnicalParameter
ASTM Standard geomembrane
| Spec Properties |
Test method ASTM |
GMS0.5 | GMS0.75 | GMS1.0 | GMS1.25 | GMS1.5 | GMS2.0 | GMS2.5 |
| Thickness | D5199 | 0.5mm | 0.75mm | 1.00mm | 1.25mm | 1.50mm | 2.00mm | 2.50mm |
| Density (≥ g/cc) | D1505 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 |
| Tensile Properties (Each direction) (≥) • yield strength • break strength • yield elongation • break elongation |
D 6693 Type IV |
8 kN/m 14kN/m 12% 700% |
11 kN/m 20kN/m 12% 700% |
15 kN/m 27 kN/m 12% 700% |
18 kN/m 33 kN/m 12% 700% |
22 kN/m 40 kN/m 12% 700% |
29 kN/m 53 kN/m 12% 700% |
37kN/m 67kN/m 12% 700% |
| Tear Resistance (≥) | D 1004 | 64 N | 93 N | 125 N | 156 N | 187 N | 249 N | 311 N |
| Puncture Resistance (≥) | D 4833 | 160 N | 240 N | 320 N | 400 N | 480 N | 640 N | 800 N |
| Stress Crack Resistance (≥) | D 5397 | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. |
| Carbon Black Content | D 1603 | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% |
| Carbon Black Dispersion | D 5596 | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) |
| Oxidative Induction Time (OIT) (≥) (a)Standard OIT - or - (b)High Pressure OIT |
D 3895 D 5885 |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
Application:
1. landfill liner&caps
Landfill liner systems are the ideal geotechnical products applied for landfilling solid waste, rubbish garbage among mountains,excavated mines, etc. Landfill liner systems are generally composed of HDPE geomembrane liner and woven geotextile or other geosynthetic products.
2. Fish and shrimp farm project
Is very important to overall water containment, protection and heath for the shrimp or fish farm ponds. High density polyethylene (HDPE) is the preferred lining material for shrimp or fish farm projects, that is to say, HDPE geomembrane liner is the best pond
liner as the true foundation of your shrimp or fish farm.
3. Pond & Lake Liners
We specialize in liners for holding water; whether that be large lake liners for golf courses and fishing lakes, or small pond liners for koi and goldfish ponds. We have a number of different liner materials that we recommend depending on your particular application.
Blue and green geomembrane
Packing and Shipping
1. Packing:
PP woven geotextile bags or PE film. Or according to customers requirements.
2. Delivery:
Within 7-10 days after receiving your deposit.
Samples are for your review.
FAQ
1. Are you trading company or manufacturer ?
A: We are manufacturer.
2. How long is your lead time ?
A: Generally it is 4-5 days.
3. Do you provide samples ? It's free or extra ?
A: Sure ,we woule like to offer the samples for free change , but pls kindly pay the cost of freight by yourself.
4. IS the size and color can be customized ?
A: Sure , the thickness, width, length and color are customzed , but pls talk the details to our sales before the order.
