Product Details:
|
| Material: | HDPE | Color: | Can Be Customized |
|---|---|---|---|
| Package: | Woven Bags | Length: | 50m-100m/roll (as Request) |
| Model Number:: | 0.5mm | Product Name: | Hdpe Geomembrane Liner |
| High Light: | 1.5mm 2mm HDPE Geomembrane Liner,HDPE Geomembrane Liner 30 mil,UV Resistant 30 mil hdpe liner |
||
APPLICATION:
1. Landfills capping prevent fluid flow in the landfill, trap and properly vent the gases generated during decomposition of organic waste and benefit to revegetation and restoration of the area.
2. Water reservoirs collecting rain-water before it reaches the sea.
3. Protection of lake banks for soil stabilization.
4. Tunnels protecting the structure against humidity and water pressure.
5. Earth dams for soil stabilization.
6. Underground insulation protecting underground water from pollution of chemicals and oil leakage of chemical plants and petrol stations.
7. Mining preventing contamination of the soil and underground water.
HDPE Geomembrane pond liner TechnicalParameter
ASTM Standard geomembrane
| Spec Properties |
Test method ASTM |
GMS0.5 | GMS0.75 | GMS1.0 | GMS1.25 | GMS1.5 | GMS2.0 | GMS2.5 |
| Thickness | D5199 | 0.5mm | 0.75mm | 1.00mm | 1.25mm | 1.50mm | 2.00mm | 2.50mm |
| Density (≥ g/cc) | D1505 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 |
| Tensile Properties (Each direction) (≥) • yield strength • break strength • yield elongation • break elongation |
D 6693 Type IV |
8 kN/m 14kN/m 12% 700% |
11 kN/m 20kN/m 12% 700% |
15 kN/m 27 kN/m 12% 700% |
18 kN/m 33 kN/m 12% 700% |
22 kN/m 40 kN/m 12% 700% |
29 kN/m 53 kN/m 12% 700% |
37kN/m 67kN/m 12% 700% |
| Tear Resistance (≥) | D 1004 | 64 N | 93 N | 125 N | 156 N | 187 N | 249 N | 311 N |
| Puncture Resistance (≥) | D 4833 | 160 N | 240 N | 320 N | 400 N | 480 N | 640 N | 800 N |
| Stress Crack Resistance (≥) | D 5397 | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. |
| Carbon Black Content | D 1603 | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% |
| Carbon Black Dispersion | D 5596 | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) |
| Oxidative Induction Time (OIT) (≥) (a)Standard OIT - or - (b)High Pressure OIT |
D 3895 D 5885 |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
HDPE Geomembrane and pond liner is produced from high density polyethylene resin by film-blowing process, adding carbon black, antioxidant, anti-aging and UV-resistance component. Now it is the most widely used products for solid waste containment (such as landfill liners), mining and water containment applications.
omembrane application industry:
1. Environmental protection, environmental hygiene(such as garbage landfill site, treatment of sewage, containment of poisonous or
harmful wastes, hazardous warehouse, industry wastes, construction & explosive rubbish, etc)
2. Water conservancy(such as waterproofing, stopping up leak, reinforcement for lake, river, channels, tunnels, dams and reserviors;
vertical wall with core, slope protection, etc)
Blue and green geomembrane
Geomembrane contruction on site:
1. It should be extended from the bottom toward the top,can not tightly pull, it should keep 1.5% margins for local stretching. To view actual conditions, the laying sequence from top to bottom is adopted for slope.
2. Two adjacent geomembrane's joints in the machine direction should not be on a level line,should be staggered over 1m. The overlap should be over 20cm.
The Life time of Our Geomembrane:
The life of a geomembrane can be as short as 10 years or as long as more than 50 years; it depends on the quality and the environmental conditions.
Packing and Shipping:
1. Packing:
PP woven geotextile bags or PE film. Or according to customers requirements.
2. Delivery:
Within 7-10 days after receiving your deposit.
Samples are for your review.
Advantage of Waterproofing Geomembrane For Landfill Site:
1. Chemical and biological erosion resistance
2. A wide using temperature range
3. Long service life
4. High tensile strength
5. Excellent anti-tearing capability
6. Excellent waterproof and anti-seepage capability
7. Low coefficient of thermal expansion, flexibility
FAQ
1. Are you trading company or manufacturer ?
A: We are manufacturer.
2. How long is your lead time ?
A: Generally it is 4-5 days.
3. Do you provide samples ? It's free or extra ?
A: Sure ,we woule like to offer the samples for free change , but pls kindly pay the cost of freight by yourself.
4. IS the size and color can be customized ?
A: Sure , the thickness, width, length and color are customzed , but pls talk the details to our sales before the order.
