Product Details:
|
| Material: | High-density Polyethylene | Color: | Black /Green/White/Tan |
|---|---|---|---|
| Thickness: | 1.25mm--1.50mm--1.75mm | Height: | 75mm--200mm |
| Solder Distance:: | 365mm~ 711mm | Peel Strength Of Welding Point:: | 1000~1420N/10CM |
| Surface Treatment:: | Smoothly Or Textured | Warranty: | More Than 5 Years |
| High Light: | Polyethylene HDPE Geocell,Roads Polyethylene HDPE Geocell,Roads HDPE Geo Cell Grid |
||
Good Selling High Density Polyethylene HDPE Geocell In Construction, Roads
The Characteristics of Geocell
The product has the characteristics of customizable size, flexible expansion, easy transportation and construction, light material, wear resistance, stable chemical properties, light and oxygen aging resistance, acid and alkali resistance, anti-skid, anti-deformation, which can enhance the bearing capacity of the roadbed and disperse the load.
How Ceocell Works
When filled with compacted materials,it creats a new composite entity that possesses enhanced mechanical and geotechnical products.
When the soil contained within Geocell is subjected to pressure,it causes lateral stress on perimeter cell walls.
| Model | Bonded Range(mm) |
▲Cell Depth (mm) |
Sheet Thickness (mm) |
Expanded Cell Size (mm) |
▲Cells Quantity | Section Size (m) |
Cells Per Section |
Section Area (m2) |
| GM356 | 356 | 75 | ≥1.25 ≥1.50 ≥1.75 |
251.45x251.45 | 10(Width) 29(Length) |
2.52x7.30 | 290 | 18.4(±1%) |
| 100 | ||||||||
| 150 | ||||||||
| 200 | ||||||||
| GM432 | 432 | 75 | ≥1.25 ≥1.50 ≥1.75 |
305.3x305.33 | 8(Width) 29(Length) |
2.44x8.86 | 232 | 21.62(±1%) |
| 100 | ||||||||
| 150 | ||||||||
| 200 | ||||||||
| GM445 | 445 | 75 | ≥1.25 ≥1.50 ≥1.75 |
314.31x314.31 | 8(Width) 29(Length) |
2.51x9.12 | 232 | 22.89(±1%) |
| 100 | ||||||||
| 150 | ||||||||
| 200 | ||||||||
| GM711 | 711 | 75 | ≥1.25 ≥1.50 ≥1.75 |
502.90x502.90 | 5(Width) 29(Length) |
2.51x14.59 | 145 | 36.62(±1%) |
| 100 | ||||||||
| 150 | ||||||||
| 200 |
