HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs

HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs
HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs

Large Image :  HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs

Product Details:
Place of Origin: CN
Brand Name: Haisan
Certification: ISO
Model Number: hs-liner
Payment & Shipping Terms:
Minimum Order Quantity: 1000㎡
Price: USD 0.2-3.5
Packaging Details: PP Woven Bag
Delivery Time: 5-10 work days
Payment Terms: L/C,T/T
Supply Ability: 1000000㎡ per month

HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs

Description
Appearance: Smooth Color: Black (standard), Other Colors Available On Request
Thickness: 0.2mm To 3.0mm Roll Length: Customized Length Accept
Feature: Anti-uv Hdpe Pond Liner Sample: Accept
Material: High-Density Polyethylene (HDPE) Lifespan: 20 To 50 Years Under Normal Conditions
Length: Customizable

HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs

Leaking water can ruin the efficiency of any agricultural or water storage setup. Our high-density geomembrane liner provides an absolute, leak-proof barrier to keep every drop of water right where it belongs. Engineered as a heavy-duty impermeable sheet, this plastic lining material prevents water from soaking away into dry or sandy ground. It is incredibly flexible, allowing it to conform easily to the slopes and corners of your dug-out pits. Ideal for large-scale agricultural irrigation canals and farm reservoirs, this tough polyethylene liner protects your subgrade soil from erosion while ensuring your water levels stay perfectly stable through the dry season.

HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs 0

HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs 1

Technical Specifications

Thickness mm
0.5
0.75
1.0
1.25
1.5
2.0
Tensile yield strength (vertical and horizontal) N/mm
≥7
≥11
≥15
≥18
≥22
≥29
Tensile breaking strength (vertical and horizontal) N/mm
≥13
≥20
≥27
≥33
≥40
≥53
Elongation at break (vertical and horizontal) %
≥700
Right angle tear strength (vertical and horizontal) N/mm
≥62
≥93
≥125
≥160
≥190
≥250
Puncture strength N
≥160
≥240
≥320
≥400
≥480
≥640
Carbon black content %
2.0-3.0

Why Choose Our Geomembranes?

  • Custom Roll Widths Available: We can manufacture extra-wide rolls up to 6 meters, reducing the number of seam welds your workers need to do on site, saving you time and labor costs.
  • Withstands Heavy Ground Movement: The plastic sheet has excellent stretchability, meaning it can bend and flex safely when the dirt underneath settles or shifts over time.
  • Easy Weld: Our material melts perfectly and evenly when using standard hot-wedge welding tools on site, creating super tight, leak-proof seams that won't pull apart.
  • No Needle Holes or Thin Spots: We use modern automated thickness sensors across our entire production line, making sure your plastic rolls have zero weak spots or tiny leaks.

HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs 2

HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs 3

Primary Applications

  • Decorative Lake Liners: Installed beneath artificial lakes in public parks or backyards to keep the water level constant without constant refilling.
  • Rainwater Harvesting Tanks: Lining large community collection pits to hold heavy stormwater runoffs without losing it to underground seepage.
  • Farm Irrigation Pits: Lining large agricultural water storage dams to save precious rainwater and well water for seasonal crop watering.
  • Commercial Duck & Poultry Ponds: Creating clean, leak-proof water basins for farm animals that stop dirty mud from mixing with their swimming water.

HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs 4

HDPE Geomembrane Liner for Agricultural Water Storage Reservoirs 5

Frequently Asked Questions (FAQ)

Q1: What is the difference between smooth geomembrane and textured geomembrane?

A: Smooth liners are standard for flat pond bottoms because they are easy to clean. Textured liners have a rough surface to prevent soil or gravel from sliding down steep slopes.

Q2: Is your Pond Liner safe for raising fish and shrimp?

A: Yes, our liner is made from non-toxic, eco-friendly virgin polyethylene resins. It will not leach harmful chemicals into the water, making it perfectly safe for aquatic life.

Q3: How do you connect the sheets of this Geomembrane Sheet on site?

A: The sheets are joined together using professional hot-wedge welding machines, which melt the edges of the liner together to create a 100% leak-proof, continuous plastic seam.


Q4: Can this Black Geomembrane stay exposed to the weather without being buried under dirt?

A: Yes, because it is packed with premium carbon black stabilizers, our impermeable liner can handle years of direct sunlight and wind exposure without becoming brittle or rotting away.
