Product Details:
|
| Material: | LDPE | Color: | Can Be Customized |
|---|---|---|---|
| Thickness: | 0.2mm-4mm | Width: | 1m~6m |
| Application: | Landfill,Pond,Fish Farm | Length: | 50-200m |
| High Light: | 100m LDPE Geomembrane Liner,100m Fish Farm LDPE Geomembrane Liner,100m 40 Mil HDPE Liner |
||
Description:
LDPE geomembrane
High density polyethylene (HDPE) geomembrane is made from quality polyethylene native resin, main ingredients of which includes 97.5% of HDPE, 2.5% of the carbon black, anti-aging agent, antioxidant, ultraviolet absorbent, stabilize and so on, by means of automatically HDPE geomembrane manufacturing equipment via the three layer co-extrusion technology. product quality is stable, in the domestic leading level in the new, All products are manufactured based on the GRI standard and the ASTM testing standards with stable quality in a domestic leading level. We have all specifications of geomembranes that can be used in such harsh conditions of environmental sanitation, water conservancy, construction, municipal engineering, landscape architecture, landscape, petrochemical, mining, salt, agriculture, aquaculture and other engineering fields. It can be used up to 5-20 years in exposure conditions.
LDPE Geomembrane pond liner TechnicalParameter
ASTM Standard geomembrane
| Spec Properties |
Test method ASTM |
GMS0.5 | GMS0.75 | GMS1.0 | GMS1.25 | GMS1.5 | GMS2.0 | GMS2.5 |
| Thickness | D5199 | 0.5mm | 0.75mm | 1.00mm | 1.25mm | 1.50mm | 2.00mm | 2.50mm |
| Density (≥ g/cc) | D1505 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 | 0.940 |
| Tensile Properties (Each direction) (≥) • yield strength • break strength • yield elongation • break elongation |
D 6693 Type IV |
8 kN/m 14kN/m 12% 700% |
11 kN/m 20kN/m 12% 700% |
15 kN/m 27 kN/m 12% 700% |
18 kN/m 33 kN/m 12% 700% |
22 kN/m 40 kN/m 12% 700% |
29 kN/m 53 kN/m 12% 700% |
37kN/m 67kN/m 12% 700% |
| Tear Resistance (≥) | D 1004 | 64 N | 93 N | 125 N | 156 N | 187 N | 249 N | 311 N |
| Puncture Resistance (≥) | D 4833 | 160 N | 240 N | 320 N | 400 N | 480 N | 640 N | 800 N |
| Stress Crack Resistance (≥) | D 5397 | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. | 300 hr. |
| Carbon Black Content | D 1603 | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% | 2.0-3.0% |
| Carbon Black Dispersion | D 5596 | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) | Note(1) |
| Oxidative Induction Time (OIT) (≥) (a)Standard OIT - or - (b)High Pressure OIT |
D 3895 D 5885 |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
100 min. 400 min. |
Application:
1. As liners for potable water
2. As liners for waste liquids (e.g., sewage sludge)
3. As liners for secondary containment of underground storage tank
4. As liners for brine solutions
5. As liners for the aquiculture industry, such as fish/shrimp pond
6. As liners for golf course water holes and sand bunkers
7. As liners for various waste conveyance canals
8. As liners for vertical walls: single or double with leak detection
9. As waterproof facing for masonry and concrete dams
10. As cutoffs within zoned earth dams for seepage control
Blue and green geomembrane
Geomembrane production
LDPE geomembrane is made by 100% virgin materials
Geomembrane adopted the first class automatic production equipment and three-layer pressing technology. All geomembrane quality is meeting with GB, GRI and ASTM test standard.
Packing and Shipping
1. Packing:
PP woven geotextile bags or PE film. Or according to customers requirements.
2. Delivery:
Within 7-10 days after receiving your deposit.
Samples are for your review.
FAQ
1. Are you trading company or manufacturer ?
A: We are manufacturer.
2. How long is your lead time ?
A: Generally it is 4-5 days.
3. Do you provide samples ? It's free or extra ?
A: Sure ,we woule like to offer the samples for free change , but pls kindly pay the cost of freight by yourself.
4. IS the size and color can be customized ?
A: Sure , the thickness, width, length and color are customzed , but pls talk the details to our sales before the order.
