Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface

Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface
Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface

Large Image :  Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface

Product Details:
Place of Origin: CHINA
Brand Name: HASSAN
Certification: CE ISO9001
Model Number: PVC
Payment & Shipping Terms:
Minimum Order Quantity: 5,000 square meters
Price: $0.16 - $1.80/ Square Meter
Packaging Details: Standard Export Packing
Delivery Time: 5-15days
Payment Terms: L/C, T/T
Supply Ability: 30,000 square meters per day
Contact Now

Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface

Description
Material: PVC Color: Can Be Customized
Place Of Origin:: Shandong, China Thickness:: 0.2mm-3mm
Width:: 1m-8m Or Follow Clients' Demand Length: 50m/roll,100m/roll,150m/roll Or Follow Clients' Request
Standard: ASTM GRI-GM13-GM17/China Standard
Highlight:

Geosynthetics PVC Geomembrane Liner

,

150m Textured PVC Geomembrane Liner

,

Geosynthetics Geomembrane Pond Liner

Geosynthetics Smooth PVC Geomembrane Pond Liner



Products Description
Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface 0
PVC Geomembrane (High-Density Polyethylene)
PVC geomembrane liners are the preferred product for lining projects. PVC liners are resistant to many different solvents and
are the most widely used geomembrane liner in the world. Although PVC geomembrane is less flexible than LLDPE, it provides higher
specific strength and can withstand higher temperatures. Its exceptional chemical and ultraviolet resistance properties make it an
extremely cost-effective product.
Specification
1) Thickness: smooth surface 0.2mm - 3.0mm, textured surface 1.0-2.0mm
2) Width: smooth furface 1m-8m, rough surface 4m-8m
3) Length: 50m-200m/ roll or as requested.
4) Material: HDPE, LDPE, LLDPE,PVC
5) Color: black, white, blue, green.
6) Optional surface: smooth surface, single surface textured, dual surfaces textured.
Thickness
0.75
1
1.25
1.5
2
2.5
3
Density g/m2
≥0.94
≥0.94
≥0.94
≥0.94
≥0.94
≥0.94
≥0.94
Tensile yield strength (N/mm)
≥11
≥15
≥18
≥22
≥29
≥37
≥44
Tensile breaking strength (N/mm)
≥20
≥27
≥33
≥40
≥53
≥67
≥80
Bongation at yield(%)
≥12
≥12
≥12
≥12
≥12
≥12
≥12
Elongation at break(%)
≥700
≥700
≥700
≥700
≥700
≥700
≥700
Tear resistance(N)
≥93
≥125
≥160
≥190
≥250
≥315
≥375
Puncture strength(N)
≥240
≥320
≥400
≥480
≥640
≥800
≥960
Tensile load stress cracking
≥300
≥300
≥300
≥300
≥300
≥300
≥300
Carbon black content(%)
2.0-3.0
2.0-3.0
2.0-3.0
2.0-3.0
2.0-3.0
2.0-3.0
2.0-3.0
Properties

Features:

1) Good physical and mechanic performance
2) High tearing resistance, strong deformation adaptability
3) Puncture-resisting, aging resisting, ultra-violet radiation, oil and salt, and corrosion resistance
4) Good adaptability to high and low temperature, non-toxicity, long service life
5) Good waterproof, drainage, anti-seepage and damp proof effects
6) Complete width and thickness specifications, low cost and easy installation.

Benefits:

* The most chemically resistant member of the polyethylene family due to its dense configuration.
* Field welded with hot wedge welders and extrusion welders. These factory quality welds are virtually stronger than the sheet itself.
* The best QC-QA testing capabilities in the marketplace.
* No need to cover the liner because it is UV stable and cost-effective.
* Available in roll stock and come in varying thicknesses ranging from 20 to 120 mil depending on your requirements.

Technical Notes:

* HDPE is a very technical product to work with. It must be installed by certified welding technicians using specialized welding equipment to ensure performance.
* Installations are temperature and poor weather sensitive.
* 40 mil HDPE liner requires extra effort to ensure that the subgrade is in excellent condition. It is suitable as an upgrade
from products like the 20 mil RPE for larger installations and is an excellent secondary containment liner on multi-layer
systems (for example; subgrade, geotextile layer, 40 mil HDPE layer, drainage net layer, 60 mil HDPE layer, geotextile layer,
fill.)
* 60 mil HDPE liner is the staple of the industry and is suitable for most applications.
* 80 mil HDPE liner is a thicker design for more aggressive subgrades.
Application



* Irrigation ponds, canals, ditches & water reservoirs
* Mining heap leach & slag tailing ponds
* Golf course & decorative ponds
* Landfill cells, covers, & caps
* Wastewater lagoons
* Secondary containment cells/systems
* Liquid containment
* Environmental containment
* Soil Remediation
Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface 1
Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface 2
Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface 3
Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface 4
Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface 5
Geosynthetics PVC Geomembrane Liner Pond 150m Per Roll Textured Surface 6
